JSON to Video API: Render an MP4 From One Request

A JSON to video API takes one JSON document that describes the canvas, the timing and every layer, and returns an MP4. With Renderly you send that document as inputProps to POST /api/v1/renders. You do not need a saved template. Check it for free on the preview endpoint first. The 5-second card on this page costs 0.5 credits.

The finished video

This page uses Daily Social Card - Quote, an 8-second 1080x1080 card with an intro, a quote scene and a sign-off. The JSON in this guide rebuilds its quote scene by hand as a 5-second card, with four layers, so you can see every field the renderer reads.

What you need

• A Renderly API key. Create one in the dashboard under Settings → API keys.
• Code that builds the JSON. Any language that can send an HTTPS request works.
• Public URLs for any image, video or audio file the video uses.

Step 1 - Set the canvas and the length

The top level of inputProps holds the canvas. width and height are pixels and default to 1920 and 1080. fps defaults to 30. durationInFrames has no default, so a body without it returns a 400. A 5-second video at 30 fps is 150 frames. backgroundColor fills the frame behind every layer.

The canvas size also sets the price. Up to 1920x1080 pixels costs 1 credit per minute, up to 2560x1440 costs 2, and anything larger costs 4.

Step 2 - Place each layer on the canvas

overlays is a flat list of layers on one timeline. Every layer needs these fields:

Text sits in content. Media sits in src. Three details cause most failed requests:

• fontSize is a string such as "84px". A bare number returns a 400. Add fontSizeFixed: true to render at exactly that size. Without it the size is a maximum, and long text shrinks to fit its box.
• Animation lengths (enterDuration, exitDuration) are seconds, not frames.
• Give layers that overlap different rows. Two layers on the same row collide.

The overlays reference lists the styles fields for each type.

Step 3 - Preview the JSON for free

Send the body to POST /api/v1/previews before you render it. The endpoint takes exactly the body the render endpoint takes, costs no credits and creates no render job. It returns a previewUrl that plays the video in a browser, a quote in credits, and a warnings list. Two warnings matter most for hand-built JSON:

• UNKNOWN_FIELD names each field the schema does not know. The API removes it and renders without it, so a misspelled fontSizee gives no error, only a video that looks wrong.
• TEXT_MAY_CLIP names text that is likely too long for its box.

The previewing guide covers the full response.

Step 4 - Send the JSON to the render endpoint

This request renders the card. It passed the API's own schema check with no removed fields:

curl -X POST https://renderly.video/api/v1/renders \
  -H "Authorization: Bearer $RENDERLY_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "inputProps": {
      "width": 1080, "height": 1080, "fps": 30, "durationInFrames": 150,
      "backgroundColor": "#1C1815",
      "overlays": [
        { "id": 1, "type": "text", "content": "“",
          "from": 0, "durationInFrames": 150, "row": 2,
          "left": 96, "top": 60, "width": 360, "height": 360,
          "styles": { "color": "#C9512A", "fontFamily": "Playfair Display",
            "fontWeight": "800", "fontSize": "300px", "fontSizeFixed": true,
            "lineHeight": "1", "animation": { "enter": "scale" } } },
        { "id": 2, "type": "text", "name": "the_line", "isDynamic": true,
          "content": "We suffer more in\nimagination than in\nreality.",
          "from": 0, "durationInFrames": 150, "row": 0,
          "left": 110, "top": 384, "width": 920, "height": 300,
          "styles": { "color": "#F2ECE0", "fontFamily": "Geist",
            "fontWeight": "700", "fontSize": "84px", "fontSizeFixed": true,
            "lineHeight": "1.08", "textAlign": "left",
            "animation": { "enter": "slideUp" } } },
        { "id": 3, "type": "shape", "content": "rectangle",
          "from": 15, "durationInFrames": 135, "row": 3,
          "left": 110, "top": 738, "width": 64, "height": 4,
          "styles": { "fill": "#C9512A" } },
        { "id": 4, "type": "text", "name": "attribution", "isDynamic": true,
          "content": "SENECA",
          "from": 15, "durationInFrames": 135, "row": 1,
          "left": 200, "top": 718, "width": 500, "height": 44,
          "styles": { "color": "#F2ECE0", "fontFamily": "JetBrains Mono",
            "fontWeight": "600", "fontSize": "28px", "fontSizeFixed": true,
            "letterSpacing": "4px", "textAlign": "left",
            "animation": { "enter": "fade" } } }
      ]
    },
    "webhookUrl": "https://api.yourapp.com/hooks/renderly"
  }'

The response's data object carries a jobId, mode: "direct" and creditsUsed: 0.5. A render.completed event reaches your webhookUrl when the MP4 is ready, and GET /api/v1/renders/{jobId} returns its outputUrl in data too. The webhooks guide covers the signature check, and the rendering guide covers polling. If an image, video or sound layer has an empty src, the API returns a 400 that names the layer, and charges no credits.

Step 5 - Mark the fields that change per video

Two layers above carry a name and isDynamic: true. Keep the JSON fixed in your code, and add a replacements object next to inputProps in the same request body:

"replacements": {
  "the_line": "Ship the small\nversion first.",
  "attribution": "TUESDAY NOTES"
}

A replacement changes content on text and shape layers and src on image, video and sound layers. A key that matches no dynamic layer changes nothing, and the preview reports it as UNKNOWN_REPLACEMENT. For the full binding model, and for when to save the JSON as a project instead, see dynamic video templates.

What this costs at scale

Renderly bills 1 credit per minute of output at 1080p or less, rounded up to the nearest half credit. The 5-second card rounds up to 0.5 credits.

The same card at 3840x2160 costs four times the rate. At 5 seconds it still rounds up to 0.5 credits, but a one-minute 4K video costs 4.

Where to go next

To render the same data at 9:16 and 16:9, see the multi format guide. To render in each customer's brand, see the white label guide. To send one request per row of a file, the CSV guide loops over the rows.
